cases.
If your a live musician or sound designer, artist, home studio user or just a synth head like me, then you know how important it is to have a reliable and well deisgned case for you modular synth. Not only do our cases provide a secure and protective home for your valuable equipment, but they also offer a convenient and incognito way to transport & use your modular synth.
Made with virtually indestructible twin walled aluminium sides, they are built like flight cases with structural fittings palced internally and braced with steel corner braces for extra strength, honey comb polypropylene top & bottom panels.
Standard cases are made with a 70mm internal depth base, good for most modules and 50mm height in the lid to accomodate a patched system. There are three profiles available for you to mix and match the most appropriate configuration for your system. Larger systems or messy patches could benefit with a deeper lid.
Base
-
Skiff 50mm
-
Standard 70mm
-
Deep 104mm
Lid
-
Skiff 35mm
-
Standard 50mm
-
deep 70mm
-
extra deep 104mm
We've partnered with the top guys at Elevator Sound to offer these cases. They hold stock of the most common HP and U sizes in standard 70mm internal base depth and patchable 50mm internal lid depth. Click their logo to head over and check cases on offer and have a look at their awesome synths
If you would prefer a non standard case. a strange hp or a different base lid combination, skiff or deep, want a custom hp size to fit other gear or have some other specific project in mind, click the damaru logo and you'll be taken to our custom case page
 |
|---|
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Made using very strong twin walled aluminium profile, tough abs plastic corners pieces.
Available in anodised silver or powder coated black. Along with Appropriate coloure matched hardware & rivets.
The top and bottom panels are made with strong lightweight 5mm honeycomb polypropylene boards, offering 40% weight savings over standard plywood
case details.
Cases are supplied with M3 threaded inserts, kitted out high quality flightcase hardware, including lift off hinges and butterfly latches. 50hp to 84hp 6u & 7u case are supplied with briefcase D shaped handles and 104hp 6u upwards are made with heavy duty strap handles.
Custom cases can be made for any planned project. Pedal boards, volca set ups, desk top cases, all can be made to order to your prefered dimesnions.
-
3u 4u 6u 7u
-
Anodised Silver or Powder Coated Black
-
42hp 64hp 84hp 104hp 126hp
-
Fittings in either black or silver, with colour matched rivets
-
lid: 35mm internal height, 45mm overall
-
lid: 50mm internal height, 60mm overall
-
base: 50mm internal depth, 60mm overall
-
base: 70mm internal depth, 80mm overall
-
base 105mm internal depth, 114mm overall
